SKU
5DBSBT-DB-145-P16S
U.S. Air Filtration Polyester Pulse Jet Filter Bag, 5 x 145 in
5" Dia. x 145" L Poly
Specifications
5" Dia x 145" Long Polyester Felt Filter Bag. Polyester media is a common filter media due to its excellent filtration properties and low cost. It has an operating temperature of 275°F and is suitable for a wide range of applications.
Not sure this is the right filter? Give us a call at (888) 221-0312 and talk with a parts specialist.
Not sure this is the right filter? Give us a call at (888) 221-0312 and talk with a parts specialist.
$16.75
In Stock
Specifications
Part Number
5DBSBT-DB-145-P16S
Type
Top Load
Filter Media
Polyester Felt
Media Weight
16oz
Finish / Membrane
Singed
Top Construction
Double Beaded Snap Band
Tube Sheet Dia.
5.00"
Bag Diameter
4.93"
Overall Length
145"
Bottom Construction
Disc Bottom
Mean Air Permeability
32 - 39 cfm/ft²/min @ 0.5" H20
Operating Temperature
<265°F
Recommeded Maximum Continuous Temperature
265°F
Bag Flat Width
7.75"
Brand
U.S. Air Filtration
