SKU
6DBSBT-DB-121-A14S-WC
U.S. Air Filtration Aramid Pulse Jet Filter Bag, 6 x 121 in
6" Dia. x 121" Long Aramid Filter Bag
Reliable Filtration, 400° Operating Temperature
Specifications
Engineered for efficiency in high temperature applications, this high-quality aramid filter bag delivers exceptional performance in operating temperatures up to 400°F. Used in a wide variety of applications including asphalt plants, cement plants, metal processing, and power plants.
Designed for a precise fit and secure seal, this bag features a double beaded snap band size for a 6.00" tube sheet, a 5.85" diameter body, and a 121" length, and a double stitched disc bottom with 3" wear cuff for enhanced durability and performance.
Contact us for other size, construction, and material options.
Not sure this is the right filter for your system? A parts specialist is ready to help! Call us at (888) 221-0312 or chat online with a live person now.
Designed for a precise fit and secure seal, this bag features a double beaded snap band size for a 6.00" tube sheet, a 5.85" diameter body, and a 121" length, and a double stitched disc bottom with 3" wear cuff for enhanced durability and performance.
Contact us for other size, construction, and material options.
Not sure this is the right filter for your system? A parts specialist is ready to help! Call us at (888) 221-0312 or chat online with a live person now.
$42.40
In Stock
Specifications
Part Number
6DBSBT-DB-121-A14S-WC
Type
Top Load
Filter Media
Aramid Felt
Media Weight
14oz
Finish / Membrane
Singed
Top Construction
Double Beaded Snap Band
Tube Sheet Dia.
6.00"
Bag Diameter
5.85"
Overall Length
121"
Bottom Construction
Disc Bottom w/ Wear Cuff
Mean Air Permeability
36 - 39 cfm/ft²/min @ 0.5" H20
Operating Temperature
<445°F
Recommeded Maximum Continuous Temperature
400°F
Bag Flat Width
9.25"
Brand
U.S. Air Filtration
